LS239 Automotive Paint Meter Expert Edition
Rich in functions, simple mode and expert mode optional
1.Switch freely between simple and expert modes for versatile functionality.
2.Auto-detects ferrous putty and iron galvanized with a 3-color backlight prompt.
3.Fast measurement, completing in 0.3 seconds.
4.Stores up to 999 vehicle detection records.
The coating thickness gauge is professionally used for the measurement of the painting film thickness of car bodies. Generally, car bodies are made of metal materials, such as iron and aluminum, and non-metal materials, such as carbon fiber and plastics. The gauge can measure the painting film thickness on the ferrous and aluminum materials. Moreover, it can identify not only non-metal car bodies, but also the ferrous putty layer as well as the galvanized iron. With 3 color backlight, it makes the measurement results clear at a glance. The instrument also integrates Bluetooth function, which can use cell phone APP or WeChat mini program to record the paint thickness value of different parts of the car and the corresponding shell material, and can generate test reports and information plates to share with friends.
Parameters
| Probe tip | Ruby |
|---|---|
| Measurement principle | Fe: Hall effect / Al: Eddy current |
| Probe type | Integrated |
| Measuring range | 0.0-5000μm |
| Resolution | 0.1μm/1μm/10μm |
| Accuracy | 0-3000μm: ≤±(3%H+2μm), H is the standard value 3000-5000μm: ≤±(5%H+2μm), H is the standard value |
| Unit | μm / mil |
| Measuring interval | 0.5 s |
| Minimum measuring area | Ø = 25mm |
| Minimum radius of curvature | Convex: 5mm / Concave: 25mm |
| Minimum substrate thickness | Fe:0.2mm / Al:0.05mm |
| Display | 192×64 dot matrix LCD |
| Power supply | Rechargeable lithium battery 3.7V@1200mAh |
| Range of working temperature | -20℃-50℃ |
| Storage temperature range | -20℃-60℃ |
| Host size | 108*70*31 mm |
| Weight (including battery) | 88.8g |
| Data transfer | Bluetooth |
Features
Rich functions and easy operation
With five operation buttons, the instrument offers rich functionality and simple operation, making it suitable for various scenarios and easy for users to master quickly.
Simple mode and expert mode optional
Supports free switching between simple mode and professional mode to meet the needs of different users.
Expert mode offers component detection for vehicles
Each vehicle has 19 component groups, with 6 measurement points stored for each component, providing more accurate assessment of the vehicle's condition.
Intelligent identification of ferrous putty
The instrument intelligently detects the ferrous putty layer, displaying a prompt on the screen while the backlight turns red and emits two beeps, making it easy to determine if a car has been repaired.
Automatic recognition of vehicle body substrate
The instrument can quickly detect iron, aluminum, galvanized iron and non-metallic vehicle bodies. It is a multi-purpose machine that can easily identify vehicle body substrates.
Customized alarm value
Users can set custom alarm values, triggering a warning when measurements exceed the preset threshold.
Three-color backlight display
When the tricolor display is enabled, the instrument adjusts the backlight color based on the measured paint thickness: If the thickness falls between the "Below Lo Limit" and "Above Hi Limit," the backlight is white. If the thickness is between the "Above Hi Limit" and "Severe Hi Limit," or between the "Below Lo Limit" and "Severe Lo Limit," the backlight turns yellow. If the thickness exceeds the "Severe Hi Limit," falls below the "Severe Lo Limit," or if iron powder putty is detected, the backlight turns red.
Fast measurement speed
The instrument has an ultra-fast response speed and can complete a measurement in 0.3s.
Wide measurement range, up to 5000μm
The instrument boasts an extensive measurement range, capable of measuring thicknesses of up to 5000μm.
Massive data storage
In simple mode, the device can store 60 measurement data, and in expert mode, it can store 999 vehicle data. It can measure 19 different parts of a vehicle, with each part storing up to six measurements.
Equipped with the App for generating inspection reports
Featuring Bluetooth data transmission capability, it can connect to the mobile App for measurements, generate test reports, and save or share them effortlessly.
Digital probe for precise measurements
Equipped with advanced digital probe technology, the instrument processes signals directly at the probe, reducing interference and ensuring exceptional accuracy and stable data performance.
Durable ruby measuring probe
The instrument features a wear-resistant ruby measuring probe, reducing measurement errors from abrasion and enhancing longevity.
Rotatable display screen for easy reading
In simple mode, you can choose to turn on the rotating screen. Short press the up and down buttons to rotate the screen, making reading more convenient.
Continuous measurement function
During the test, press the probe for 2 seconds and slide it to enter the continuous measurement. If the current measurement mode is the simple mode, the instrument will display the maximum and minimum values under continuous measurement.
Built-in temperature compensation for accurate measurements
Supports six display languages
Rechargeable lithium battery lasts over 50 hours per charge
Switchable units: micrometers and mils
Qualifications and Standards
Standards for the product:
DIN EN ISO 2808 Paints and Varnishes-Determination of Film Thickness
JJG-818-2005 Verification Regulation of Magnetic and Eddy Current Measuring Instrument for Coating Thickness
GB/T 4956-2003 Non-magnetic Coatings on Magnetic Substrates-Measurement of Coating Thickness-Magnetic Method
GB/T 4957-2003 Non-conductive Coatings on Non-magnetic Basis Metals-Measurement of Coating Thickness-Eddy Current
Videos
LS239 Operation Video
Packing
| S/N | Item | Quantity | Unit |
|---|---|---|---|
| 1 | Coating thickness gauge | 1 | set |
| 2 | Fe zero adjustment plate | 1 | pcs |
| 3 | Al zero adjustment plate | 1 | pcs |
| 4 | Standard film | 1 | pcs |
| 5 | User manual | 1 | pcs |
| 6 | Certificate/Warranty card | 1 | pcs |
